P7.62 SMD Indoor Full Color LED Screen Wall

  • Indoor LED Display
  • Model: LLP-IFP7.62MM
  • Leadtime: within 15 Days
  • Warranty: 2 Years
  • Product description: P7.62 SMD full color LED screen Wall is ideally suited for indoor applications requiring close and medium viewing distance. It's widely placed at shopping malls, airports, stadiums, etc
  • INQUIRY

P7.62 SMD Indoor Full Color LED Screen Wall

- Cost effective and less maintenance;
- High brightness and terrific color uniformity;
- Suitable for both fixed and rental installations;
- Good protection against dust, moisture, static, etc;
- Calibration technology on the LED lamps is supported;
- With fiber optic cable to avoid signal delay for long distance transmission;
- User friendly software operation, all programs can be digitally edited;
- High compatibility with all kinds of video formats on its playing software.

Specifications:

1 Pixel pitch
7.62mm
2 Pixel density
27,777 pixels/sq.m
3 Pixel configuration
1R1G1B, SMD3525 or SMD2121, 3-in-1
4 LED module size (L*H)
244*122mm or 244*244mm
5 LED module resolution
32*16 pixels
6 LED cabinet size (L*H*D)
732*732*80mm or as requested
7 LED cabinet resolution
96*96 pixels
8 LED screen wall cabinet weight
14.5KG/panel with aluminium alloy
9 LED screen wall cabinet material
Diecasting aluminum/aluminium alloy/iron at customer's request
10 Brightness
≥1,600 nits/sq.m
11 Driving method
1/8 scan
12 Viewing angle
140°H /140°V
13 Best viewing distance
>7.2M
14 Refresh rate
≥800Hz
15 Grey scale
≥4,096 levels
16 Display colors
>16.7M
17 Power consumption
Max.:1,200W/sq.m, Avg.:480W/sq.m
18 Input voltage
110~230V/AC (±10%)
19 Input power frequency
50/ 60Hz
20 IP rating (front/rear)
IP43
21 Operating environment
Temperature: -20°C~+50°C, Humidity: 10%~95%
22 Storage environment
Temperature:-40-50°C, Humidity: 10-90%
23 Life span (50% brightness)
≥100,000 hours
24 Control system
LINSN or other popular control systems
25 Transmission distance
Multi mode fiber <500m, single mode fiber <30Km, internet cable <100m
26 Operating system
Windows XP/Win7//8/Vista
27

Video input/with video processor:

Rgblink,Vdwall,Magnimage,etc

VGA,DVI,DHMI,SDI,RGB,CVBS,HD-SDI,etc
28 Compliant standard
CE/UL/RoHS
